DES EMC
DES EMC split frames are used when quick grounding of shielded cables is required. The frames are treated with a special silver-coated copper conductive paint while the grommets are made from TPE with special conductive material.
Due to the mechanical connection to the panel made by the fixing screws, grounding of the shielded cables is ensured without generating additional noise often created by the external metal brackets that become antennas.
Categories:
DES EMC Series
Download PDF
- Multiple configurations with small and large grommets
- Large surface area in contact with the cable (21 mm)
- Excellent cable grip due to multi-range grommet
- Antistatic protection
- High attenuation of EMI radiations
- Frame screws in AISI304 Stainless Steel
- Robust construction IK10
- Threaded inserts version on request
- Material: PP+GF with silver-coated copper conductive outer finish
- Flammability: self-extinguishing according to UL94-V0
- Temperature: -40°C… +100°C (static)
- Properties: halogen-free, silicone-free
