Our high-quality pump uses a unique diaphragm that diffuses less than 0.5ppm of oxygen while drawing from pressures as low as 14” Hg. It pushes the sample gas through the trace oxygen analyzer allowing the sensor to operate at atmospheric pressure. Electrochemical oxygen sensors must operate at or very close to atmospheric pressure for accurate operation. Prior sample pump technologies used various types of diaphragm materials, which either allowed too much oxygen to diffuse or alternatively developed small leaks allowing air to be drawn into the system.
Categories: SOLUTIONS, Analyzers, AMI | Analyzer (O2, H2s, Moisture), Accessories
| Area Classification | : Class 1, Div.2, Group C,D |
| Connections | : ¼” SS compression fittings |
| Power | : 12VDC @ 750ma |
| Pressure range | : 14”Hg. to 10psig. |
| Dimensions | : 7.5W x 6.0”H x 4.5”D |
