Delta F nondepleting oxygen sensor

Delivering ultra-stable, trace oxygen analysis in industrial gas applications The Delta F non-depleting, coulometric oxygen sensor provides ultra-stable oxygen measurement and requires only an annual span calibration. Combined with Panametrics’ moisture.IQ, this offers a cost effective six-channel solution for multipoint oxygen measurement covering ppm and ppb measurements. The Delta F sensor is particularly suited to applications requiring high sensitivity measurements for process control.

Categories: Panametrics | Moisture and Gas Analysers

Download PDF

Used with moisture series analyzers to measure oxygen concentration in gases from trace to percent levels
Ultralow range for ultrapure gas applications is sensitive to less than 5 ppb oxygen
Sensors available for indoor/outdoor water- and dust-tight enclosures
No gas scrubbing equipment needed for acid gas applications
No periodic replacement or reconditioning of cells is needed
Intrinsically safe option available for hazardous areas
Optional VCR fittings for enhanced system cleanliness and leak integrity

Ambient temperature	: 24 VDC ±2 VDC, 1.2 A maximum
Moisture	: 316 stainless steel, glass and Viton® O-rings
Inlet pressure	: 0.2 psig to 1.0 psig (0.013 barg to 0.06 barg) (standard range)
Flow rate	: 0.5 to 1.5 SCFH
