The universal SensoTrans DMS A 20220 strain gauge transmitters provide connection possibilities for all standard strain gauge force transducers and strain gauge load cells in full-bridge configuration. They can be flexibly adapted to the respective measuring task using DIP and rotary encoder switches or via a “teach-in function“. 3-port isolation with protective separation up to 300 V AC/DC according to EN 61140 ensures optimum protection of personnel and equipment as well as unaltered transmission of measuring signals. The SensoTrans DMS A 20220 offers maximum performance in the smallest of spaces. Adjusting the zero point and sensitivity to the individual strain gauge sensor is particularly convenient using the “teach-in function“ – just at the push of a button at the device front. Sensors with known characteristics can be very easily calibrated using four rotary encoder switches and eight DIP switches.
Categories: Transmission & Signal, Knick | Interface
| Ambient temperature | : 0 to +55 °C |
| Design | : Modular housing with screw terminals, 6.1 mm wide See dimension drawings for further measurements. |
| Mounting | : For 35-mm DIN rail acc. to EN 60715 |
| Weight | : Approx. 60g |
