8-CH Thermocouple/ MV Input Module / RS485 Modbus RTU Z-8TC
The Z-8TC module acquires up to 8 single-ended signals (voltage-type, from the: signal generator or thermocouple) and it converts them to a digital format (normalized measure).
Categories:
Automation & IOT, Seneca | Automation Interface, RTUs
Download PDF
- It is possible to choose if measure is voltage (mV) or temperature (°C) type, for each couple of input signals: IN1 and IN2, IN3 and IN4, IN5 and IN6, IN7 and IN8
- It is possible to enable/disable each input
- Configuration of a filter applied to each couple of input signals
- It is possible to enable/disable cold-junction compensation, for each couple of input signals
- It is possible to configure module (node) address and baud-rate by Dip-Switches
- It is possible to add/remove the module to/from RS485-bus without disconnecting the communication or power supply
- It is possible to switch automatically from RS485 to USB or vice versa
| Resolution |
: 14bits (if filter=0-1); 15 bits (if filter=2-7) |
| Sampling frequency |
: Configurable between: 48Hz |
| Rejection |
: 50Hz or 60 Hz |
| Accuracy Initial |
: 0.1% of E.E.S. |
