RS232 ↔ M-Bus serial Adapter Z-MBUS

Z-MBUS adapter, connected to the serial port COM1 - RS232 of Seneca Z-TWS4, Z-PASS2-S S6001-RTU and other controllers, allows the support of M-Bus networks by powering up to 25 M-Bus devices per module. Alternatively, with the Micro USB port on board, you can access to the M-Bus network from a PC. From the webserver interface integrated in SENECA controller it is possible to scan / configure / diagnose Z-MBUS slave devices. The management of M-Bus devices is done through integrated tools in the web server configuration, scanning, diagnostics and appropriate IEC 61131 Straton reading function block.

Categories: Automation & IOT, Seneca | Automation Interface, RTUs

Download PDF

Power supply : 11..40 Vdc; 19..28 Vac (@50-60 Hz) from both terminals and rear IDC10 connector
Operating temperature : -20..+70°C
Connections : Nr.1 M-BUS port.
Nr.1 RS232 port, Nr.1 Micro USB port, Nr.1 IDC10 connector (power supply), Nr.1 M-BUS port (METER-BUS)

Number of slave nodes: 25.
Max- Speed: 300 – 38.400 bps.
M-BUS Voltage: 28 Vdc.
Maximum distance: 3.000 m.
Mounting: On omega DIN rail IEC EN 60715.

Power supply	: 11..40 Vdc; 19..28 Vac (@50-60 Hz) from both terminals and rear IDC10 connector
Weight	: 140 g
Dimension	: (wxhxd) 100 x 17,5 x 112 mm
Operating tempeature	: -20..+70 °C
Protection degree	: IP20
