Z-5DI2-DO 7-CH, 5 Digital Inputs, 2 Digital Outputs Module, RS485 – Modbus RTU
Z-5DI-2DO is a mixed digital module with Micro USB front port of programming, 5 digital inputs (Redd, Proximity, PNP, NPN, contact) selectable via software, nr.5 totalizers @ 32bit with maximum frequency 5 kHz and settable forwards or backwards, nr.2 SPST relay outputs 2 A 250 Vac NO / NC type selectable via jumper. All totalizers are stored in non-volatile memory (FeRAM).
Categories:
Automation & IOT, Seneca | Automation Interface, RTUs
Download PDF
- NR 5 opto-insulation digital inputs with a common contact. Internal or external, NPN (sink) or PNP (source) selectable by software.
- Insulation of the 1500 Vac inputs complying with respect to the remaining low voltage circuits.
- NR 2 SPST relay outputs with common contact, capacity of 2 AAC1 250 Vac.
- 3 kVac insulation between the outputs and the remaining low voltage circuits.
- Inputs with 32 bit totalizers, max frequency 5 KHz.
- Measure of the period, frequency, TON, TOFF. Max frequency 5KHz.
- Possibility to set the totalizers for counting forward or backward
- All the totalizers are saved in a non-volatile memory (Fe-RAM).
Refer to the datasheet for more details.
