Strain gauge converter Z-SG / Z-SG-L
Z-SG / Z-SG2 are strain gauge load cell converters. The measurement, carried out with 4 or 6-wire technique, is available via ModBUS RTU serial protocol or analog output. The communication is configurable via DIP-switch or via software by connecting to the device with the Micro USB port on the front panel.
Categories:
Automation & IOT, Seneca | Automation Interface, RTUs
Download PDF
- ADC with 24bit resolution
- 4 wires or 6 wires load cell measure mode
- Compression and Traction or only compression load mode
- NR 1 analog output configurable in Current or Voltage mode (only Z-SG model)
- Load cell sensitivity configurable from +-1mV/V to +-64mV/V or virtually every sensitivity
- Measure resolution configurable
- RS232 and RS485 port with Modbus RTU protocol
- Configurable Moving average filtering
- Digital input for Tare acquisition (only Z-SG model)
- General purpose Digital input or Digital output (only Z-SG-L model)
- Digital output with one configurable weight threshold or “stable measure” condition
- Modbus Station address and baud-rate configurable by Dip-Switches
| Resolution |
: 24bits |
| Rejection |
: 50Hz or 60Hz |
| Supply voltage |
: 10 – 40 Vdc or 19 – 28 Vac ( 50Hz – 60Hz) |
