Universal input with pid controller Z-DAQ-PID
The Z-DAQ-PID module acquires one universal input signal (voltage, current, potentiometer, thermo-couple, thermo-resistance, m-voltmeter) and converts it to an analog format (with PID regulation).
Categories:
Automation & IOT, Seneca | Automation Interface, RTUs
Download PDF
- Three operating mode: conversion with PID regulator, conversion without PID regulator, manual (constant output configurated through ModBUS register).
- Two output types: analog or ON/OFF (time of high-state digital signal is directly proportional to the analog signal)
- Universal input: voltage, current, potentiometer, thermocouple (TC), RTD (Resistance Temperature Detector) , m-voltmeter.
- Analog Output: voltage type, active current type, passive current type Slew-rate, burn-out, output limiters setup.
- Modbus address and baudrate configurable by Dip-Switches.
| Input Number |
: 1 |
| Filter |
: Configurable between: 0 (no filter is applied), from 1 (min) to 19 (max) |
| Response time |
: Sampling time + 6 ms |
| Voltage-type IN |
: Scale range is configurable: from 0 V to 10 V. Input impedance:>5M |
