K121 is a high performance universal converter / isolator designed to convert main analog signals (mA, mV, V, PT100, Pt1000, Pt500, Ni100, TCs, Ohm) and turn it into 4..20 mA loop powered signal. The module offers best-in-class accuracy (0,1%, 16 bit) and reduced response time (Voltage and Current input) @140 ms. The output mode (normal/inverted), scale overrange, output in case of fault sensor are selectable parameters by PC software EASY SETUP / EASY LP. A 2-way galvanic isolation among input // output circuits assures the integrity of your datas.
Categories: Automation & IOT, Seneca | Automation Interface, RTUs
|
Power supply |
: 7..30 Vdc (from loop 4..20mA) Side Power |
|
Hot swapping |
: Yes |
|
Current consumption |
: 24 mA |
|
Power consumption |
: <660 mW A/D Conversion 16 bit |
|
Rejection |
: 50 o 60 Hz (configurable) |
