K111D is a frequency divider (up to 256 pulses at input) with input signal repeater function. It has an isolated and stabilized power supply, front LED light for power and output status. Galvanic isolation for signals from On / Off sensors is 1.500 V. The instrument accepts several types of input signals up to 20 kHz, selectable for 2/3-wire sensors: NPN 12 / 24V, PNP, PNP 12 / 24V, photoelectric impulse, IEC 1131-1 contact, Namur, Reed. The 2 independent outputs are high-current PNP type (up to 200 mA) internally protected against short-circuiting.
Categories: Automation & IOT, Seneca | Automation Interface, RTUs
| Max current consumption | : < 25 mA |
| Max power consumption | : 500 mW |
| A/D conversion | : 14 bit |
| Rejection | : 50 – 60 Hz |
