Acquisition of digital signals from sensor: reed, NPN, PNP, proximity, contact, etc.

Configuration of a filter applied to input signals IN1-IN8 (noise filter) to attenuate the noise overlapped to the digital signals.

Pulse counters for digital signals IN1-IN8, with max frequency equal to 10kHz, 32bit-registers.

Advanced management of the pulse counters for digital signals IN1-IN8 (for each pulse counter: overflow, preset value and reset/preset command are available).

Power of 24 sensors using internal supply voltage (Vaux=16V).

It is possible to configure the module (node) address and baud-rate by Dip-Switches.

It is possible to add/remove the module to/from RS485-bus without disconnecting the communication or power supply.

It is possible to switch automatically RS485 to RS232 or vice versa.

CAN interface with CANOpen protocol: max 1Mbps.

Type  : Polarity (EN 61131 – 2 type 2): sink (pnp)

RS485 interface : IDC10 connector for DIN 46277 rail (back-side panel)

Supply voltage : 10 – 40 Vdc or 19 – 28 Vac ( 50Hz – 60Hz)

Power consumption : Typical: 1.5W; Max: 2.5W

Switching delay Typical : 1.2ms; max: 3ms

Adsorbed current : 3mA (for each input)
